✅Product Details:
🟢Brand: LEMONTALK
🟢Name: SC to SC UPC Fiber Optic Patch Cable
🟢Model: 0154
🟢Connector Type : SC to SC Male Plug
🟢Fiber Type:Single Mode 9/125
🟢Fiber Grade:G.657.A
🟢Polarity:A(Tx) to B(Rx)
🟢Fiber Mode:9/125um
🟢Jacket OD:2.0mm
🟢Material (External) : PVC;
🟢Insertion loss:≤0.3dB
🟢Return loss:≤ 50dB
🟢Number of plug: ＜1000 times
🟢Attenuation at 1310 nm:0.36 dB/km
🟢Attenuation at 1550 nm:0.22 dB/km
🟢Minimum Bend Radius:30mmApplications
🟢Working temperature: -40~+80°C
🟢Storage temperature range: -40~+85°C
🟢Cable Length : 1M, 2M, 3M, 5M, 10M, 20M
🟢Applications: Optical fiber communication systems; Optical fiber access networks; Optical fiber data transmission; Local area network (LAN)
✅Features：
⭐️1. Core Type: Single-mode (SM: 9/125um)
⭐️2. Cable Diameter: φ2.0mm
⭐️3. Low insertion loss and back reflection loss
⭐️4. Good echangeabilityGood Durability
⭐️5. High temperature stability
⭐️6. CE,ROHS,FCC
📦 Package Included:1 x SC to SC UPC Fiber Optic Patch Cable
