Features
*Excellent Mechanical,Small Size
*High Reliability
*Low insertion Loss and low Polarization Dependent loss
*High channel counts
*Excellent Environmental Stability and Widely Used
Applications
*FTTx Deployments(GPON/BPON/EPON)
*Cable television (CATV)
*Local area networks (LAN)
*Test equipment
*Passive optical networks(PON)
|
11xN (with connector) |
|||||||||||||
|
(Number  of Channels) |
1×2 |
1×4 |
1×8 |
1×16 |
1×32 |
1×64 |
2×2 |
2×4 |
2×8 |
2×16 |
2×32 |
2×64 |
|
|
(Operating  Wavelenth) |
1260 to 1650 |
||||||||||||
|
P Â Level Insertion Loss |
4 |
7.4 |
10.5 |
13.7 |
17 |
20.3 |
4.4 |
7.6 |
10.8 |
14.1 |
17.4 |
20.7 |
|
|
S Â Level Insertion Loss |
4.2 |
7.6 |
10.7 |
14 |
17.3 |
20.7 |
4.6 |
7.9 |
11.2 |
15 |
18.1 |
21.7 |
|
|
(Uniformity) |
0.4 |
0.6 |
0.8 |
1 |
1.2 |
1.6 |
0.8 |
1 |
1.2 |
1.5 |
1.8 |
2 |
|
|
(PDL) |
0.2 |
0.3 |
0.3 |
0.3 |
0.3 |
0.5 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.5 |
|
|
(Return  Loss) |
more than 55 |
||||||||||||
|
(Directivity) |
more than 55 |
||||||||||||
|
(Type  of fiber) |
ITU Â G657A |
||||||||||||
|
(Operating  temperature) |
-40 to 85 |
||||||||||||
|
(Pigtail  length) |
1m or 1.5m  or customized |
||||||||||||
Ordering Information
|
PLCS |
Port Type |
Cable Type |
Fiber Length |
Connector Type |
Package Style |
|
PLC Splitter |
1*4 1*8 1*16 1*32 1*64 2*32 Others Specify |
0.25mm Bare fiber Ribbon Fiber Fan-out with 0.9mm Loose Tube 2.0mm Cable 3.0mm Cable |
1 mete 1.5 meter specify |
FC/APC FC/PC SC/APC SC/PC ST/UPC LC/APC Others Specify |
Stainless steel sleeve Plastic Module 19 1U Rack Mount Others Specify |
