10Pcs1m SC/UPC-SC/UPC Simplex 9/125 Single Mode SM Optic Cable Patch Cord Fiber Extension Jumper
Product Details:
Name: SC to SC UPC Fiber Optic Patch Cable
Connector Type : SC to SC Male Plug
Fiber Type:Single Mode 9/125
Fiber Grade:G.657.A
Polarity:A(Tx) to B(Rx)
Fiber Mode:9/125um
Jacket OD:2.0mm
Material (External) : PVC;
Insertion loss:≤0.3dB
Return loss:≤ 50dB
Number of plug: 1000 times
Attenuation at 1310 nm:0.36 dB/km
Attenuation at 1550 nm:0.22 dB/km
Minimum Bend Radius:30mmApplications
Working temperature: -40~+80°C
Storage temperature range: -40~+85°C
Cable Length : 1M
Features:
1. Core Type: Single-mode (SM: 9/125um)
2. Cable Diameter: φ2.0mm
3. Low insertion loss and back reflection loss
4. Good echangeabilityGood Durability
5. High temperature stability
6. CE,ROHS,FCC
Package Included:1 x SC to SC UPC Fiber Optic Patch Cable
