For this loop detector, it has 220V-250V only, no 12V, no 24V , no 110V
Â
Â
 Main Features Â
1) Standard industrial guide installation
2) Strong anti-jamming ability and stability
3) Variety of output interface adapted to different scene
4) High temperature stability
5) Reset Switch : The reset switch enables the detector to be manually reset duringÂ
  commissioning and testing . This results in the detector re-tuning the sensing loop and
  becoming ready for vehicle detection ;
6) Selectable Pulse Time : This feature sets the length of time that the pulse relay will be
  energized for 1 Second or 0.5 Seconds ;
7) Pulse Relay Selection : The Pulse Relay may be configured to energize on detection of a
  vehicle or when the vehicle leaves the loop ;
8) Sensitivity Boost : This feature sets the undetect level to maximum sensitivity and is used Â
  to prevent loss of detection of high-bed vehicles ;
9) Switch Selectable Sensibility : 4 sensitivity setting are available on the switches to allow
  flexibility in configuration ;
10) Switch Selectable Frequency : 4 frequency settings are available to prevent cross-talk
  between adjacent loops ;
11) Filter Option : This option is used to provide a delay between detection of the vehicle and
  switchiing of the output relay . This relay is normally used to prevent false detection of
  small or fast moving objects ;
12) Permanent Presence Option : This feature ensure detection of the vehicle will be maintained
  when the vehicle is parked over the loop for extended periods .
