Alcatel Lucent G-010S-P ONU Stick – Choose from Flashed or Original Firmware Versions (Pre-Owned)
Welcome to our listing for the Alcatel Lucent G-010S-P ONU Stick. This product is available in two versions: a flashed version with custom firmware and an original firmware version. Both versions support high-speed GPON connections and are ideal for those looking to replace their original modem with a more compact device.
Key Features
– High-Speed Performance: Supports 2.5G BitRate (Rx/Download) and 1.25G BitRate (Tx/Upload), providing a robust and efficient connection.
– Compatibility: Tested and verified by multiple Nokia/Alcatel-Lucent modem users. Works seamlessly with SFP+ routers, SFP+ switches, and media converters.
– Easy Installation: Features a green SC/APC fiber connector, identical to the original modem, allowing direct plug-and-play without the need for conversion cables.
Flashed Version
– Third-Party Firmware: Pre-flashed with the latest third-party firmware and modified with pin 6 short-circuited for compatibility with most switches and routers. Capable of achieving at least 1G speed handshake; however, 2.5G speed handshake requires a MultiGiga-capable switch/router.
Original Firmware Version
– Original Firmware: The ONU stick comes with its original firmware. Suitable for tech enthusiasts who wish to experiment with or modify the firmware themselves.
– Access Information: The original firmware version does not include access credentials. Login information is unknown and cannot be provided.
Product Specifications
– Model: Alcatel Lucent G-010S-P
– Type: GPON SFP ONT
– Compliant Standards: G.984.x (1/2/3/4/5)
– Optics: 1490 nm wavelength downstream, 1310 nm wavelength upstream
– Line Rate: 2.488 Gb/s downstream, 1.244 Gb/s upstream
– Connector: SC/APC
– Power Consumption: <2W
– Temperature Range: -40°C to 85°C (-40°F to 185°F)
– Humidity Range: 5% to 95%
– Dimensions: Small Form-Factor Pluggable (SFP)
Benefits
– Compact Size: Minimal space required to convert an Ethernet box into a GPON-capable device.
– Easy to Install: Simple plug-and-play design for quick setup.
– Enhanced End-User Experience: Upgrade existing devices to GPON fiber connectivity effortlessly.
– Low Power Consumption: Efficient and environmentally friendly.
– Wide Compatibility: Ideal for business services and remote node applications.
Important Notes
1. Heat Dissipation: The ONU stick may generate significant heat. It is recommended to use it in an air-conditioned room or with an additional heatsink. Contact customer service if you need a heatsink.
2. Tested Functionality: Each product is tested to ensure proper functionality. However, we do not provide technical support. Please purchase cautiously if this is a concern.
How to Choose the Correct Version
– Flashed Version: Choose this if you want a plug-and-play solution with custom firmware, ensuring compatibility with most switches and routers.
– Original Firmware Version: Choose this if you prefer to experiment with the original firmware and do not need immediate access to login credentials.
Upgrade your network today with the Alcatel Lucent G-010S-P ONU Stick and experience high-speed, reliable connectivity like never before!
—————————————————————————————————————————————————–
Here's a simplified English instruction manual for the G-010S-P ONT (Optical Network Terminal) :
1. Cable Connections:
1. Insert the G-010S-P ONT into the SFP port of the optical receiver.
2. Connect the RJ45 network cable from the optical receiver to a home network switch or router.
*(Note: The home network segment must be 192.168.1.x. Otherwise, you will not be able to access the G-010S-P ONT backend. If it's not, please change it to this segment.)*
2. Configuration:
1. After completing the above connections, log in to the router backend and you should see a new device with IP 192.168.1.10 or 192.168.2.10, which is the G-010S-P ONT.
2. Within the local network, enter 192.168.1.10 in your browser's address bar to access the G-010S-P ONT backend.
– Username: root
– Password: null
3. In the G-010S-P ONT backend, set the LOID and VLAN ID (you may need to enter the original optical modem's super admin backend to obtain these):
– GPON SN: 12-digit SN (usually on the back of the optical modem)
– LOID: Fill in the LOID you obtained
– Logic Password: Usually leave blank
– PLOAM Password: Fill in the password you obtained
4. After successful configuration, save and apply, then restart the G-010S-P ONT and check the registration status (ensure the optical cable is connected).
3. Important Notes:
1. The optical network path must be GPON. EPON users cannot use this device (please check before purchasing, non-refundable if incorrect).
2. Ensure LOID and VLAN ID are correctly set to register normally.
—
This guide helps you set up and configure the G-010S-P ONT to ensure a proper connection and functionality within your home network.
