Product Description
B03CG Laser Level Features:
⭐FULL LAYOUT WITH 3 X 360 LINE LASER ⭐CONVENIENT TYPE-C CHARGING & DURABLE DESIGN
⭐VERSATILE LASER TOOL
⭐GREEN LASER & OUTDOOR PULSE MODE
⭐KIT CONTENTS.
⭐VERSATILE LASER TOOL
⭐GREEN LASER & OUTDOOR PULSE MODE
⭐KIT CONTENTS.
Type-C Charging Port:
* This laser tool utilizes the included large capacity of 3.7V / 5200mAh lithium battery and provides up to 8 hours of running
time.
* The lithium battery with the Type-C charging port can be charged separately.
* Direct input charging: When taking out the battery, the laser tool can be used at the job site by plugged in.
* Four battery indicators on keypad allow users to know the current battery volume.
* Charging protection helps prevent from overcharging.
More Installation Methods:
* 1/4″-20 female thread on the laser level can help to mount it to the tripod or laser mounting pole.
* 360° Strong Magnetic Pivoting Base: Allows being adsorbed onto metal track and steel. The base provides 360° free rotation to
meet different angles required.
* 1/4″-20 and 5/8″-11 mounting threads on the bottom of the bracket for temporary fastening in place or being fixed on tripod or
laser mounting pole.
* Replaceable Protective Cover: The laser windows can be removed and replaced with a screwdriver.
* Green Target Plate: Increases the visibility of the laser beam.
Pulse Mode
Turn ON pulse mode: Slide the pendulum to the Unlocked Position, then press and hold the power button to turn on the pulse mode,
the indicator lights up in red.
Application：When the pulse mode turned on, laser tool can be used with a laser receiver to work in brighter condition or a larger
working distance.
●When use with a receiver, it’s necessary to turn on the pulse mode ●It is compatible with Huepar Line Laser Receiver only.
Self-leveling mode & Manual mode
Self-leveling mode:
When the laser tool is switched to the unlocked position, self-leveling mode is enabled. The laser beam will blink continuously at
2Hz when the tool is beyond self-leveling range (4°±1°)
Manual mode:
When the pendulum lock is in locked position, manual mode locks laser lines in place for use at any angle to project non-level
straight lines. The laser beam will blink every 3-5 seconds to remind you that it’s not self-leveling now.
When the laser tool is switched to the unlocked position, self-leveling mode is enabled. The laser beam will blink continuously at
2Hz when the tool is beyond self-leveling range (4°±1°)
Manual mode:
When the pendulum lock is in locked position, manual mode locks laser lines in place for use at any angle to project non-level
straight lines. The laser beam will blink every 3-5 seconds to remind you that it’s not self-leveling now.
Diverse Power Supply
Large-capacity lithium battery: 6 hours of extra-long working are available. Bare battery charging:Lithium battery with type-c port Direct input charging: This laser tool can be used at job site with direct input charging even if take out the battery.Charging protection help prevent the tool from overcharge.
Practical and Durable
The kit comes with a hard carry case that brings much more convenience to carry and store of the laser level. The overall TPR soft rubber housing as well as compact design makes the laser tool more durable and portable. This laser offers a 1/4″-20 mounting thread for being fixed on mount or tripod. Strong Magnetic L mount allows for attachment to metal track and steel, supporting users to operate the laser level at 360 degree.
Specification
|
Laser Class: Class 2 (IEC/EN60825-1/2014), <1mW power output
|
|
Laser Wavelength: 505-520nm
|
|
Horizontal/Vertical Accuracy: +/- 1/9 inch at 33Ft
|
|
Leveling/Compensation Range: +/-4°
|
|
Working Distance (Line): 130Ft (100 LUX), 200Ft with Huepar Receiver LR-5RG/LR-6RG
|
|
Operating Time: 6 hours continual use with all laser beams on
|
|
Power Source: 5200mAh Li-ion battery
|
|
IP Rating: IP54 dust-proof, waterproof and shockproof, reliable and tough
|
|
Operation Temperature Range: 14℉ ~ 122℉ (-10℃~ 50℃)
|
|
Mount Size: 1/4″-20
|
Packing & Delivery
Title goes here.
* 1 x B03CG Green Beam Self-Leveling 3D Cross Line Laser Level
* 1 x 360° Magnetic Pivoting Base
* 1 x Rechargeable Lithium Battery With Type-C
* 1 x Type-C Power Cord
* 1 x Power Adapter
* 1 x Laser Target Plate
* 1 x User Manual
* 1 x Hard Carry Case
* 1 x 360° Magnetic Pivoting Base
* 1 x Rechargeable Lithium Battery With Type-C
* 1 x Type-C Power Cord
* 1 x Power Adapter
* 1 x Laser Target Plate
* 1 x User Manual
* 1 x Hard Carry Case
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
